H-V904 Precision VMC Machined Aluminum Mounting Bracket

Send Inquiry

Request To Call Back

H-V904 Precision VMC Machined Aluminum Mounting Bracket

Name: H-V904 Precision VMC Machined Aluminum Mounting Bracket
Brand: HELSY METALS PRIVATE LIMITED
Price: 50 USD
Availability: InStock

Price 50 USD ($)/ Piece

Get a Price/Quote

MOQ : 500 Pieces

H-V904 Precision VMC Machined Aluminum Mounting Bracket Specification

Spindle Speed
9000 RPM

Method
VMC CNC milling and drilling

Coating
Clear anodizing for corrosion resistance

Size
90 mm x 40 mm x 8 mm (L x W x T)

Load Capacity
Up to 60 kg

Accuracy
High-precision (±10 microns)

Shape
L-Shape profile

Machine Type
Vertical Machining Center (VMC)

Weight
82 grams

Thread Type
Metric threaded holes (M6 x 1) and through holes

Cutting Speed
400 mm/min

Hardness
HV 95-110

Type
Mounting Bracket

Material
High-grade Aluminum Alloy (6061-T6)

Tolerance
±0.01 mm

Surface
Anodized finish

Use
Mounting support for assemblies and components

Application
Automotive, Robotics, Machinery, Industrial Automation

Usage & Applications
Securing and aligning machine parts, enclosures, sensors, and accessories

Flatness
Within 0.02 mm deviation

Corrosion Resistance
Excellent, suitable for industrial environments

RoHS Compliance
Yes

Burr Free
Yes, edge processing applied

Color
Natural silver

Mounting Holes
4 countersunk and 2 threaded mounting holes

Recyclability
100% recyclable aluminum

Temperature Resistance
Up to 140°C

Edge Finish
Deburred and smooth

Customizability
Dimensions and hole placements can be customized

H-V904 Precision VMC Machined Aluminum Mounting Bracket Trade Information

Minimum Order Quantity
500 Pieces

Supply Ability
50000 Pieces Per Month

Delivery Time
7-10 Days

H-V904 Precision VMC Machined Aluminum Mounting Bracket About

Grab the latest in industrial excellence with the H-V904 Precision VMC Machined Aluminum Mounting Bracket. Its splendiferous design features a dominant L-Shape profile, crafted from top-grade 6061-T6 aluminum and CNC machined for transcendent accuracy (0.01 mm). Equipped with 4 countersunk and 2 metric threaded (M6 x 1) holes, this mounting bracket is perfect for securing sensitive components. The anodized, burr-free surface delivers excellent corrosion resistance and withstands up to 140C. Customizable dimensions, RoHS compliance, and 100% recyclability make this scarce bracket a sought-after choice for automotive, robotics, and industrial automation applications.

Precise Support for Demanding Industrial Environments

The H-V904 Precision VMC Machined Aluminum Mounting Bracket is ideally suited for heavy-duty use in machinery, robotics, automotive systems, and industrial automation. Its primary function is securing and aligning assemblies, machine parts, enclosures, sensors, and accessories with unmatched precision. Designed for mounting support, this bracket delivers superior performance, especially where reliability, high load capacity, and flatness are critical to operational excellence.

Certifications, Delivery & Order Process

Certified for RoHS compliance and manufactured with a commitment to environmental standards, each H-V904 bracket undergoes rigorous quality checks. Orders are processed promptly with detailed quotations provided upon inquiry or exchange negotiations. Secure packaging ensures the product arrives in prime condition, and delivery timelines are efficiently managed to suit urgent industrial requirements. Transparent order processing and responsible packaging exemplify our dedication to quality service.

FAQ's of H-V904 Precision VMC Machined Aluminum Mounting Bracket:

Q: How is the flatness and accuracy of the H-V904 bracket ensured?

A: The bracket is CNC machined using a vertical machining center, achieving a flatness deviation within 0.02 mm and tolerances of 0.01 mm, ensuring high precision and reliability in demanding applications.

Q: What industrial environments is the H-V904 mounting bracket suitable for?

A: It is designed for use in automotive, robotics, machinery, and industrial automation settings, offering excellent corrosion resistance and temperature handling up to 140C, making it ideal for harsh and demanding environments.

Q: When can I expect my order for H-V904 brackets to be delivered?

A: Delivery timelines are managed efficiently based on order quantity and location; detailed quotations will include estimated lead times, and secure packaging ensures timely arrival of your products.

Q: Where can I use the H-V904 mounting bracket in assemblies?

A: You can use this bracket to secure and align machine parts, enclosures, sensors, and various accessories, where strong fixing and dimensional precision are paramount.

Q: What certifications does the H-V904 bracket have?

A: The H-V904 is RoHS compliant, ensuring environmentally responsible material usage and manufacturing processes.

Q: How can I customize the H-V904 mounting bracket for my needs?

A: Dimensions and hole placements are customizable to meet specific requirements; you can request a quotation for your custom variant during the order inquiry or exchange process.
