H-V892 VMC Machined Copper Flanged Housing

Name: H-V892 VMC Machined Copper Flanged Housing
Brand: HELSY METALS PRIVATE LIMITED
Price: 50 INR
Availability: InStock

Price 50 INR/ Piece

Get a Price/Quote

MOQ : 500 Pieces

H-V892 VMC Machined Copper Flanged Housing Specification

Cutting Speed
120 - 250 m/min

Thread Type
Metric or Custom Threads Available

Size
As per Specification Drawing

Accuracy
10 Microns

Coating
Bare Copper (Uncoated)

Machine Type
Vertical Machining Center (VMC)

Spindle Speed
3500 - 8000 rpm

Load Capacity
Supports Up to 35kN

Shape
Flanged Cylindrical Housing

Hardness
80-90 HV

Weight
Variable, Typically 105-250g per unit

Method
CNC Milling & Turning

Type
Machined Component

Material
High-Purity Copper

Tolerance
0.01 mm

Surface
Smooth Copper Finish, Deburred

Use
Flanged Mounting for Mechanical Assemblies

Application
Electrical Terminals, Mechanical Housings

Usage & Applications
Used in Motors, Generators, Switchgear, Conductive Mounts

Flange Outer Diameter
55 mm 0.05 mm

Packaging
Individual Poly Sleeve, Export Cartons

Flange Thickness
7 mm

Electrical Conductivity
98% IACS

OEM Capability
Supported

Rust Proofing
None (Copper is Naturally Resistant)

Density
8.96 g/cm

Finish Options
Optional Tin or Nickel Plating On Request

Customisation
Fully Custom Sizes and Threads Available

Body Length
62 mm 0.05 mm

Operating Temperature
Up to 450C

Mounting Holes
4 Holes, M8 x 1.25 Thread

Lead Time
4-7 Working Days

Inspection
Dimensional and Visual Inspection Per Batch

Copper Grade
Cu-ETP (Electrolytic Tough Pitch), ASTM B152

H-V892 VMC Machined Copper Flanged Housing Trade Information

Minimum Order Quantity
500 Pieces

Supply Ability
50000 Pieces Per Month

Delivery Time
7-10 Days

H-V892 VMC Machined Copper Flanged Housing About

Jump on the extraordinary H-V892 VMC Machined Copper Flanged Housing-your first-class solution for demanding electrical and structural applications. Manufactured from valiant high-purity Cu-ETP copper (ASTM B152), this flanged cylindrical housing features precise VMC CNC machining with 0.01 mm tolerance and a smooth deburred finish. Supporting loads up to 35kN, offering high conductivity (98% IACS), and fully customizable for size, threads, or finishes, it's a true bargain for OEMs, suppliers, and exporters. Get it now with individual poly sleeves, export cartons, and a swift 4-7 day lead time!

Other Features & Application Method

The H-V892 Copper Flanged Housing excels with its extraordinary precision, achieved through first-class Vertical Machining Center (VMC) CNC technology. It supports metric or custom threads, fully deburred, and ensures accuracy within 10 microns. Designed for flanged mounting, it's ideal for mechanical assemblies, motors, generators, switchgear, and conductive mounts. Direct integration is seamless-simply mount using 4 M8 holes. Optional plating and customizations offer versatile performance for valiant engineering challenges.

Export Markets, Supply Ability & Payment Terms

The main export markets for the H-V892 Copper Flanged Housing encompass Europe, Asia, North America, and the Middle East. With a reliable rate of supply and shipment logistics, orders are processed within a 4-7 working day lead time for prompt dispatch. Flexible payment terms are available to facilitate international trade. Each shipment is securely packaged in individual sleeves and export cartons to ensure safe transit and delivery worldwide.

FAQ's of H-V892 VMC Machined Copper Flanged Housing:

Q: How is the H-V892 VMC Machined Copper Flanged Housing typically used in industrial applications?

A: This housing is commonly applied in electrical terminals, mechanical assemblies, motors, generators, switchgear, and conductive mounts, thanks to its flanged mounting design and robust copper construction.

Q: What is the process for customization of size, thread, or finish for OEM orders?

A: Custom specifications are welcomed; simply provide your drawing or specification for size, thread type (metric or custom), and finish preference (bare, tin, or nickel plating). The manufacturer will review and confirm feasibility at the order stage.

Q: When can I expect shipment and delivery after placing an order?

A: Lead time for the H-V892 housing is typically 4-7 working days from order confirmation. Shipments are dispatched promptly after inspection and secure packaging to ensure rapid logistics.

Q: Where do you export the H-V892 Copper Flanged Housing?

A: We export to major markets in Europe, Asia, North America, and the Middle East, with efficient logistics and secure export packaging for global customers.

Q: What are the advantages of using Cu-ETP Copper in this housing component?

A: Cu-ETP Copper offers first-class electrical conductivity (98% IACS), valiant durability, and natural corrosion resistance, making it ideal for high-performance industrial and electrical environments.

Q: How is each batch inspected to ensure quality and performance?

A: Each batch undergoes dimensional and visual inspection to ensure all specifications and surface quality meet the required standards before shipment.
