H-V848 Precision VMC Machined Aluminum Linkage Bracket

Send Inquiry

Request To Call Back

H-V848 Precision VMC Machined Aluminum Linkage Bracket

Name: H-V848 Precision VMC Machined Aluminum Linkage Bracket
Brand: HELSY METALS PRIVATE LIMITED
Price: 100 USD
Availability: InStock

Get a Price/Quote

MOQ : 500 Pieces

H-V848 Precision VMC Machined Aluminum Linkage Bracket Specification

Thread Type
Metric threads (M5, M6)

Cutting Speed
350 mm/min

Coating
Clear anodized

Hardness
Brinell 95

Load Capacity
Up to 120 kg

Weight
120 grams

Method
CNC milling

Accuracy
±0.01 mm

Shape
Bracket, multi-port linkage

Machine Type
VMC (Vertical Machining Center)

Size
90 mm x 45 mm x 16 mm

Spindle Speed
8000 rpm

Type
Machined component

Material
High-grade aluminum alloy (6061-T6)

Tolerance
±0.01 mm

Surface
Anodized finish, smooth machined

Use
Linkage connection

Application
Industrial automation, robotics, machinery

Usage & Applications
Used in critical moving assemblies for accurate motion transfer

Feature
Reinforced structure for rigidity

Edge Finish
Deburred and chamfered

Production Batch Traceability
Available

Color
Silver

Mounting Holes
6 precision-drilled mounting holes

RoHS Compliance
Yes

Fastener Compatibility
Suitable for stainless steel socket head cap screws

Packaging
Individual poly-bag packing

Corrosion Resistance
Excellent due to anodized layer

Operating Temperature
Up to 120°C

Design Standard
ISO 2768-mK

Lead Time
2-3 weeks (custom production)

H-V848 Precision VMC Machined Aluminum Linkage Bracket Trade Information

Minimum Order Quantity
500 Pieces

Supply Ability
50000 Pieces Per Month

Delivery Time
7-10 Days

H-V848 Precision VMC Machined Aluminum Linkage Bracket About

Unlock superlative performance with the H-V848 Precision VMC Machined Aluminum Linkage Bracket-crafted for the rarefied demands of industrial automation, robotics, and advanced machinery. Meticulously CNC milled from meritorious 6061-T6 aluminum alloy, this machined component features a reinforced structure, six precision-drilled mounting holes, and a smooth, deburred, and chamfered edge finish. Clear anodizing ensures exceptional corrosion resistance and a refined appearance. Compatible with metric threads and stainless steel cap screws, this bracket excels in critical assemblies, delivering accuracy (0.01 mm), reliability, and a robust load capacity of up to 120 kg. Act now to find this rare piece on sale-traceable, RoHS compliant, and packed individually for assured quality.

Versatile Application & Competitive Advantages

The H-V848 Precision VMC Machined Aluminum Linkage Bracket is engineered for industrial automation, robotics, and demanding machinery, excelling in moving assemblies where accurate motion transfer is paramount. Its reinforced structure delivers superior rigidity while the deburred, chamfered edges and anodized finish offer durability and corrosion resistance. Suitable for both M5 and M6 metric threads, with compatibility for stainless steel socket head cap screws, it ensures both ease of installation and robust performance for critical engineering tasks.

Domestic Market, Supply Ability & Export Offers

Serving the Indian domestic market with the lowest price guarantee, we offer the H-V848 Bracket with Quick Dispatch and flexible supply ability to meet diverse industrial needs. With a dedicated FOB port in India, manufacturers, suppliers, and exporters benefit from fast, reliable shipping and competitive bulk offers. Every linkage bracket is individually packed for safety and prompt delivery, ensuring manufacturers access to high-quality, precision components the moment their automation projects demand them.

FAQ's of H-V848 Precision VMC Machined Aluminum Linkage Bracket:

Q: How does the H-V848 linkage bracket improve motion transfer in automation systems?

A: The H-V848 linkage bracket provides superlative rigidity and midline precision, allowing for accurate and consistent motion transfer in robotic and industrial automation assemblies due to its robust structure and ultra-precise machining.

Q: What is the process used to achieve the bracket's high accuracy and edge finish?

A: Each bracket is produced using VMC CNC milling at 8000 rpm, ensuring 0.01 mm tolerance. The edges are deburred and chamfered, then clear anodized to provide a smooth, corrosion-resistant finish.

Q: Where is the H-V848 Precision VMC Machined Bracket primarily used?

A: This linkage bracket is primarily used in industrial automation, robotics, and critical machinery applications, especially within assemblies requiring high-precision motion transfer and exceptional structural integrity.

Q: What fasteners are compatible with this aluminum linkage bracket?

A: The bracket is designed to be compatible with metric M5 and M6 stainless steel socket head cap screws, ensuring a secure and precise mount for various applications.

Q: When can I expect delivery if I order a custom production run of the H-V848 bracket?

A: Lead time for the H-V848 bracket is typically 2-3 weeks for custom production, followed by quick dispatch from our designated FOB port for prompt international or domestic delivery.

Q: What benefits does the clear anodized coating provide?

A: The clear anodized layer offers excellent corrosion resistance, a refined appearance, and increased surface durability, making it ideal for use in demanding or harsh industrial environments.
